Dynamiq Jetsetter yacht in Portofino
GTT 135 | Delivered in 2021
Best Naval Architecture
Semi-Displacement Motor Yachts
41 m
Length
21 kn
Speed
5000 NM
Range
5
Guest cabins

MAIN Dimensions

GTT 135 (fleet)
Length overall 41 m / 135’
Draft 1.8 m / 5'9’’
Sun Deck length 17.7 m / 58’
Sun deck area 120 m2 / 1292 sq ft
Beam overall 8.2 m / 26’11”

Interior headroom (max)

Sun deck
2.2 meters / 7’3’’
Main deck
2.2 meters / 7’3’’
Lower deck
2.2 meters / 7’3’’

Specification

  • Hull type
    Round-bilge, fast displacement
    Length overall
    41 meters / 135’
    Beam overall
    8.2 meters / 26’11”
    Draft
    1.8 m / 5'9’’
    Gross tonnage
    299 GT
    Material
    Aluminium, 5083
    Main engines
    2x MAN V12-1650, 1,213 kW
    Generators
    2x 70 kW, Kohler
    Stabilisers
    Electrically driven, zero-speed function
  • Max speed
    21 knots
    Cruising speed (85% rpm)
    19 knots
    Range
    5,000 nm @ 10 knots
    Fuel consumption
    50 l/h @ 10 knots
    Fuel
    29,600 l / 7,820 US gallons
    Fresh water
    9,500 l / 2,245 US gallons
    Noise levels At anchor Cruising speed
    Main salon 40 dB(A) 59 dB(A)
    Owner suite 38 dB(A) 58 dB(A)
    VIP cabins 38 dB(A) 48 dB(A)
    Wheelhouse 38 dB(A) 50 dB(A)
  • Guests
    10 (+1) in 5 cabins
    Crew
    6 in 3 cabins
    Tender
    5,4 m / 17’5”
    Classification
    RINA commercial, REG compliant
    Notations
    RINA Comfort Class, RINA Green Star
    Flag
    Cayman islands / Malta
    Naval architecture
    Van Oossanen
    Exterior Design
    Dobroserdov Design
    Interior Design
    Giuseppina Arena / Dynamiq
    Build time
    20 months
